MSI SPATIUM M560 PCIe 5.0 NVMe M.2 1TB

• Support de l'interface PCIe Gen5x4 et compatible à la norme NVMe 2.0
• Vitesse de lecture séquentielle allant jusqu'à 10 300 Mb/s
• Vitesse d'écriture séquentielle allant jusqu'à 8700 Mb/s
• Maximum de 1200 téraoctets écrits
• Fonctions intégrées de protection de données et de correction des erreurs
• Capacité de stockage de 1 To à 2 To dans un format M.2 2280
• Adapté aux PC portables et de bureau
• Garantie de 5 ans

Télécharger la fiche technique

• Fiche technique

Model Name	SPATIUM M560 PCIe 5.0 NVMe M.2
Capacity	1TB
Controller	PHISON E31T
Flash Memory	3D NAND
Form Factor	M.2 2280
Interface	PCIe Gen5x4, NVMe 2.0
Compatibility	PCIe Gen5 /PCIe Gen4 / Gen3 / Gen2 / Gen1
Dimensions	80.00mm (L) x 22.00mm (W) x 2.15mm (H)
Sequential Read up to (MB/s)	10,200
Sequential Write up to (MB/s)	8,400
Random Read 4KB up to (IOPS)	1,300,000
Random Write 4KB up to (IOPS)	1,400,000
Maximum Operating Power (W)	5.9
Idle Power PS3 (mW)	50
Low Power L1.2 (mW)	3.5
Operating Temperatures	0°C – 70°C
Storage Temperatures	40°C – 85°C
Terabytes Written (TBW)	600
Mean Time Between Failure (MTBF)	Up to 1,500,000 Hours
Limited Warranty	5 Years, or the coverage for the maximum TBW as stated, whichever comes first.
Advanced Features	TRIM (Performance Optimization, OS support required) SMART (Self-Monitoring, Analysis and Reporting Technology) LDPC (Low Density Parity Check) ECC Algorithm End to End Data Path Protection APST (Autonomous Power State Transition)
